Sargent 12-MD8613G RHR 10B 80 Series MD8600 Concealed Vertical Rod Exit Device -Metal Doors, Oil Rubbed Dark Bronze

Dark Bronze, Oil Rubbed Finish

• Door Types: Metal Doors, Minimum Thickness 1-3/4" (44mm)
• For Thicker Doors: Specify Thickness, Order with 31- 4-1/2" (114mm) Minimum Stile Width
• Rail Sizes: 4 Options, Choose Based on Door Width
• Factory Cut Rails: Supplied if Door Width Provided
• E Rail: 24" to 32" Door Widths, No Cutting for 32"
• F Rail: 33" to 36" Door Widths, No Cutting for 36"
• J Rail: 37" to 42" Door Widths, No Cutting for 42"
• G Rail: 43" to 48" Door Widths, No Cutting for 48"
• Strike: 650 Top, 606 Bottom (Panic & Fire Rated)
• Dogging Feature: Hex Key Standard, Cylinder Dogging Optional (#41 Cylinder Supplied)
• Electric Options: AL (Alarm), BT (Beacon), PL (SARGuide Photoluminescent Coated), TL (SARGuide Illuminated Touchpad)
• Monitoring Options: 53 (LX Latchbolt), 54 (Outside Lever), 55 (Request-to-Exit), 56 (Remote Latch Retraction), 57 (Delay Egress & Electromagnets), 58 (Electric Dogging), 59 (Electroguard Self Contained Delayed Egress)
• Mounting Fasteners: Machine Screws Standard
• Top Bolt: Stainless Steel
• Device Centerline: 41" (1041mm) Standard, 38" (965mm) for Schools & Accessibility
